Specifications:
| Model | DQL5520S |
| Voltage | 220V50HZ/60HZ |
| Horizontal heating power (W) | 1000W |
| Side heating power (W) | 500W |
| Sealing temperature | It is related to the film thickness and the ambient temperature. Generally, the horizontal sealing temperature is 160℃ – 220℃, and the edge sealing temperature is 300℃ – 350℃. |
| Sealing time (sec) | 0.1 – 1.0s |
| Film thickness (mm) | 0.015-0.05mm |
| Capacity | 0-60pcs/min |
| Packaging Materials | POF film |
| Maximum package size (mm) | L is not limited W+H≤420 H≤200 |
| Machine Size | L1898×W1296×H1484 |
| Model | DSE6530T |
| Voltage | 380V50Hz/60Hz 3phase |
| Power (W) | 19.5kW |
| conveyor speed | 0-15m/min |
| Tunnel Size | L1500*W600*H300 |
| Conveyor loading | 15kg |
| Machine size(mm) | 1975x1172x1313mm |
