Specification:
| Model No | XT-4510-1 | XT-4510-2 |
| Description | Robot pallet wrapper | Robot pallet wrapper |
| Battery | 100AH 12V x 2pcs | 100AH 12V x 2pcs |
| Power Supply | 220V 50HZ 1phase/110V 60hz 1phase | 220V 50HZ 1phase/110V 60hz 1phase |
| Control System | PLC+Green touch screen+Speed driving board | PLC+Green touch screen+Speed driving board |
| Max Moving Speed | 60 meters/minute | 60 meters/minute |
| Film Carriage | Brake | Pre-stretch 250% |
| Max Pallet Height | 2100mm (Option Max: 2500mm) | 2100mm (Option Max: 2500mm) |
| Max Pallet Size | No limit | No limit |
| Min Pallet Size | 600 x 600mm | 600 x 600mm |
| Max Pallet weight | No limit | No Limit |
| Min Pallet Weight | 100kg | 100kg |
| Moving Motor | 0.4KW DC Motor | 0.4KW DC Motor |
| Lifting Motor | 0.2KW DC Motor | 0.2KW DC Motor |
| Film Carriage Motor | / | 0.35KW DC Motor |
| Charging time | 12 hours | 12 hours |
| Working time | 8 hours | 8 hours |
| Power | 1000W | 1200W |
| Machine Weight (NW) | 300kg | 320kg |
| Machine Dimension L x W x H |
1480 x 1170 x 2224mm | 1480 x 1170 x 2224mm |
Applicable film specification
| Film Type | Stretch film machine grade |
| Film Thickness | 17-23mic |
| Film roll inner diameter | 76mm |
| Film roll outside diameter | 250mm |
| Film width | 500mm |
| Film roll weight | 13.8kg |
